Motorized display wall mount, 50 cm of vertical travel

column silver anodized, anti collision, center of display 121,5 - 171,5 cm
Item number: SCETAWK
Product image Motorized display wall mount, 50 cm of vertical travel SCETAWK
Product image Motorized display wall mount, 50 cm of vertical travel SCETAWK-1 Product image Motorized display wall mount, 50 cm of vertical travel SCETAWK-2 Product image Motorized display wall mount, 50 cm of vertical travel SCETAWK-3 Product image Motorized display wall mount, 50 cm of vertical travel SCETAWK-4 Product image Motorized display wall mount, 50 cm of vertical travel SCETAWK-5 Product image Motorized display wall mount, 50 cm of vertical travel SCETAWK-6 Product image Motorized display wall mount, 50 cm of vertical travel SCETAWK-7

Product description

Motorized display wall mount for 42"-100" (interactive) flat-panel displays.

The SCETAWK is designed for flat panel displays up to 100”. The units feature a sturdy display mount with integrated cable management and "pull & release" locking brackets for quick and easy mounting of the display.

The SCETAWK display wall mount comes with a column that offers 50 cm of vertical travel.

The unit comes flat-packed in 2 cartons and is courier-shippable.


Features

  • Heavy duty mount for displays up to 100"
  • "Pull & Release" brackets for easy mounting of display
  • VESA pattern, max. 800 x 600
  • Integrated cable management
  • 50 cm of smooth motorized height adjustment, actuator 1500N, 47 mm/ 1.85" per second
  • 4 Levelling feet + 2 wall mounting brackets for maximum stability
  • Anti-collision feature

Icon display mounts
Display mount
Icon wallmounted system
Wall mounted
Icon electrical height adjustable
Motorized height adjustable
Icon single display
Single display
Icon 5 years warranty
5 years warranty
Icon maximum load
Max. load
299.8 lbs
Icon maximal VESA
Max. Vesa
800 x 600
Item numberSCETAWK
Vesa horizontal300 mm - 800 mm
Vesa vertical200 mm - 600 mm
Frame for all55" - 100"
Vertical travel50 cm
Center to floor distance 1215 mm - 1715 mm47.8" - 67.5"
Load capacity136 kg 299.8 lbs
Width 890 mm35"
Height 1535 mm - 2035 mm60.4" - 80.1"
Depth 165 mm6.5"
Warranty5 years limited warranty
Frame colorRAL 9005 deep black
Column colorSilver anodized
Packages Package dimensions WxHxD Package weight
AF-SCETA-N900 x 160 x 450 mm / 35.4 x 6.3 x 17.7"14 kg / 30.9 lbs
Total weight 14 kg / 30.9 lbs
